It is suitable for sterilizing high-temperature-resistant appliances, glass porcelain cups, ceramics, production supplies, currency, non-woven fabrics, composite paper, cleaning appliances, tableware, towels, clothes, shoes, packaging materials and other products. The use of three-sided high-intensity sterilization, the use of synergistic ultraviolet and ozone sterilization, ozone disinfects areas that are not exposed to UV rays, kill the surface of the virus or bacteria.
Technical parameters:
Model | BJPX-SVO200 | BJPX-SV200 |
Type | with ozone | without ozone |
The wavelength of the UV ray | 253.7/184.9 nm | 253.7 nm |
Mode of sterilization | 2 faces of UV rays + 1 face of ozone | 3 sides of UV rays |
Capacity | 200L |
Power | 120W |
Power supply | Standard: 220V 50/60Hz, optional: 110V 50/60Hz |
UV lamp material | Quartz glass |
Shelves | Standard 2 pcs, can be optional |
Internal Dimension (mm) | 518*523*778 |
Outer dimension (mm) | 750*663*1200 |
Package size (mm) | 875*788*1265 |
Gross weight (kg) | 100 |
Recommended UV exposure time
Species of microorganisms | Exposure dose | Exposure time |
Bacterial propagules | ≥10000uw.s/cm2 | Ten minutes |
Bacterial spores | ≥100000uw.s/cm2 | Ten minutes |
Virus | 10000uw.s/cm2≤Exposure dose ≤100000uw.s/cm2 | Ten minutes |
Fungal spores | General exposure dose ≤100000uw.s/cm2, special exposure dose 600000uw.s/cm2 | 60 min |
When the target microorganism is unknown | ≥100000uw.s/cm2 | Ten minutes |
Remarks: The suitable temperature range for ultraviolet disinfection is 20℃ ~ 40℃. If the temperature is too high or too low, the disinfection effect will be affected, and the disinfection time can be extended accordingly.
